Butt Fusion 90° Elbow
Characteristics Butt Fusion 90° Elbow
- Non-toxic: Made from non-toxic, tasteless materials, ensuring no scaling and effectively improving water quality.
- Corrosion resistance: High resistance to various types of chemicals with no electrochemical corrosion.
- No Leakage: Joints welded using butt fusion, socket fusion, and electrofusion have higher strength than the pipe itself.
- Higher flow capacity: Smooth inner walls increase delivery capacity by 30% under the same conditions compared to other materials.
- Convenient for construction and installation: Can be installed using various trenchless methods, making the process easier and more efficient.
- Lower maintenance costs: Convenient transportation and installation reduce labor intensity and improve work efficiency.
- Longevity: Designed for a service life of 50 years under reasonable conditions.
- Recycled and environment-friendly: Recyclable materials that do not scale or breed bacteria, solving the secondary pollution of drinking water.
Technical Notes
- Raw material: PE100
- Color: Black, blue, or other colors as required (OEM customization available)
- Size: Available range from 20mm to 630mm (OEM customization available)
- Connecting way: Butt fusion and socket fusion
- Pressure Rating: PN16 (SDR11), PN10 (SDR17.6)
Standards & Certs
- ISO 9001 Compliance: Manufactured in accordance with ISO 9001 standards, ensuring consistent quality and regulatory compliance.
- Product Quality Compliance: Adheres to rigorous quality standards, ensuring reliable and durable performance.
- Safety and Environmental Compliance: Designed and manufactured following strict safety and environmental guidelines, promoting sustainability and safety.
Applications of Butt Fusion 90° Elbow
- Water Supply Systems: Used in urban water supply systems for connecting pipes at right angles, ensuring a reliable and leak-proof connection in potable water distribution.
- Sewage and Drainage Systems: Essential for constructing underground sewage and drainage networks, providing durable and corrosion-resistant joints.
- Industrial Piping: Suitable for various industrial applications, including chemical processing plants, where robust and chemical-resistant connections are needed.
- Agricultural Irrigation: Used in irrigation systems to connect pipes at corners, ensuring efficient water distribution across fields.
- Gas Distribution: Employed in gas pipelines for safe and secure gas transportation, ensuring high strength and leak-proof connections.
- Construction Projects: Utilized in various construction projects for plumbing and piping installations, offering flexibility and ease of installation.
- Mining Operations: Thanks to its high impact resistance and durability, it is suitable for transporting slurry and other materials in mining operations.
Specifications for Butt Fusion 90° Elbow
| Size | Dimensions (mm) |
|---|---|
| DN75 | 150 |
| DN90 | 175 |
| DN110 | 200 |
| DN160 | 240 |
| DN200 | 290 |
| DN250 | 360 |
| DN315 | 425 |
| DN355 | 450 |
| DN400 | 517 |
| DN450 | 640 |
| DN500 | 695 |
| DN560 | 815 |
| DN630 | 895 |
When it comes to HDPE pipe fittings, the Butt Fusion 90° Elbow is a vital component for creating secure and efficient directional changes in pipelines. This guide delves into the essentials of HDPE Butt Fusion 90° Elbows, exploring their functionality, installation process, and the key advantages they offer in various applications. Whether you’re working on water supply, gas distribution, or industrial projects, understanding the role of these fittings is crucial for ensuring the integrity and longevity of your piping system.
The Question
Common FAQ
Explore comprehensive insights about Butt Fusion 90° Elbow. Please don’t hesitate to reach out to us if you have any inquiries.
Q: What is a Butt Fusion 90° Elbow used for?
A: A Butt Fusion 90° Elbow is used to connect two high-density polyethylene (HDPE) pipes at a right angle, changing the direction of the pipe system while maintaining a strong, leak-proof joint.
Q: What sizes are available for Butt Fusion 90° Elbows?
A: Butt Fusion 90° Elbows are available in a wide range of sizes, typically ranging from 20mm to 800mm in diameter, to accommodate various piping systems.
Q: What are the pressure ratings for Butt Fusion 90° Elbows?
A: Butt Fusion 90° Elbows are designed to handle different pressure ratings, commonly ranging from PN6 to PN25, depending on the specific requirements of your project.
Q: Are Butt Fusion 90° Elbows compatible with other types of pipes?
A: Butt Fusion 90° Elbows are specifically designed for HDPE pipes and may not be compatible with other materials like PVC or metal without the use of specialized adapters.
Q: How do I ensure a proper fusion joint with a Butt Fusion 90° Elbow?
A: To ensure a proper fusion joint, use a calibrated butt fusion machine, follow the manufacturer’s recommended heating and cooling times, and ensure that the pipe ends are clean and properly aligned.
Q: What are the benefits of using a Butt Fusion 90° Elbow over other types of fittings?
A: Butt Fusion 90° Elbows offer a seamless, strong connection with minimal risk of leaks, high resistance to corrosion, and the ability to handle high pressure, making them ideal for long-term use in critical piping systems.
